Drilling Mud Shale Shaker for oilfield

FOB Reference Price:Get Latest Price
US $10,000-25,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Application:
Solids Control
Place of Origin:
Shaanxi, China (Mainland)
Brand Name:
KOSUN
Model Number:
LS584
Voltage:
380V or 460V or customized
Power(W):
2x1.86kW(2x2.5HP)
Weight:
1925*4245
Features:
High Efficiency
Product name:
High Qualified Drilling Use Dry Shale Shaker
Vibratina Motion:
Linear Motion
Vibrator Model(Martin):
Short
G-force(G):
7.1(6.5-7.5 Adjustable)
Screen Dimension(mm)/(in):
585x1165/2346
Screen No.:
4
Noise(db):
<85
Weir Height(mm)/(in):
780/30
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden case or according to customer's request
Port
Shanghai / Tianjin

High Qualified Drilling Use Dry Shale Shaker

Product Description

LS584 Drilling Mud Shale Shaker is a high frequency linear-motion vibrating screen machine, equipped with four screen panels and two vibrating motors, and offering a choice of manually adjusting screen frame angle while drilling (AWD). When LS584 series Drilling Mud Shale Shaker works, the screen frame angle can be adjusted from -1° to +5° by dint of its structural design innovation. LS584 series Drilling Mud Shale Shaker can separate drilling fluid from cuttings efficiently.



KOSUN Drilling mud shale shaker strengths:

1.Fast Pre-tensioned screen frame

2.Reliable AWD :screen frame angle can be adjusted from -1° to +5°

3.Two Martin 1.86kW (2.5HP)vibrator

4.Weir Feeder

5.Largest non-blanked screen area (four screen panels):2.9

6.Oilfield proven explosion-proof Electrical Control panel

7.Fast locking device
